SOCKET WELD TEE
Product Overview
SOCKET WELD TEE - Reliable High Pressure Branch Connections
Overview
Our Socket Weld Tee is precision-forged to create secure 90° branch connections in high-pressure piping systems. Manufactured from premium-quality forged stainless steel, carbon steel, alloy steel, and duplex steel, it offers excellent mechanical strength, corrosion resistance, and long-lasting performance. Designed in accordance with ASME B16.11 standards, our Socket Weld Tee ensures leak-proof joints and reliable operation in demanding industrial environments.
- Manufactured from premium-quality forged steel
- Precision-engineered as per ASME B16.11 standards
- Leak-proof socket weld connection for maximum safety
- Excellent resistance to corrosion, pressure, and high temperatures
- Smooth internal bore for improved flow efficiency
- Precision-machined dimensions for accurate installation
- Strong, durable construction for long service life
- Suitable for oil & gas, petrochemical, chemical, power, and industrial piping applications
Dimension Details
| Size (Inch) | Size (MM) | Bore (B) | Fitting (D) | Wall (C) | Depth (J) | Ctr-Bot (A) | Body (G) |
|---|---|---|---|---|---|---|---|
| 1/2" | 15.00 | 21.80 - 22.20 | 15.00 - 16.60 | 4.09 | 10.5 | 15.50 - 17.00 | 3.73 |
| 3/4" | 20.00 | 27.20 - 27.60 | 20.20 - 21.70 | 4.27 | 13.5 | 19.00 - 20.50 | 3.91 |
| 1" | 25.00 | 33.90 - 34.30 | 25.90 - 27.40 | 4.98 | 13.5 | 22.50 - 24.00 | 4.55 |
| 1.1/4" | 32.00 | 42.70 - 43.10 | 34.30 - 35.80 | 5.28 | 13.5 | 27.00 - 29.00 | 4.85 |
| 1.1/2" | 40.00 | 48.80 - 49.20 | 40.10 - 41.60 | 5.54 | 13.5 | 32.00 - 34.00 | 5.08 |
| 2" | 50.00 | 61.20 - 61.70 | 51.70 - 53.30 | 6.04 | 17 | 38.00 - 40.00 | 5.54 |
All Dimensions in MM
Technical Dimensions
| B | D | C | G | J | A | E | F | A | E | F | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Nominal Pipe Size |
Socket Bore dia. B (Note [1]) |
Bore Diameter of Fittings, D [Note (1)] |
Socket Wall Thickness, C | Body Wall | Min Depth of Socket |
Center to Bottom of Socket, A | Laying Lengths |
Tolerances ± | End Wall Thickness Kmin |
||||||||||||||||||||
| Class Designation | Class Designation | Class Designation | 90 deg Elbows, Tees and Crosses |
45 deg Elbows | Class Designation | ||||||||||||||||||||||||
| 3000 | 6000 | 9000 | 3000 | 6000 | 9000 | 3000 | 6000 | 9000 | Class Designation | Coupl- ings, E |
Half Coupl- ings, F |
A | E | F | 3000 | 6000 | 9000 | ||||||||||||
| (mm) | (Inch) | 3000 | 6000 | 9000 | Agv. | Min. | Agv. | Min. | Agv. | Min. | Min. | Min. | Min. | J | 3000 | 6000 | 9000 | 3000 | 6000 | 9000 | |||||||||
| 6 | 1/8 | 11.2 10.8 |
7.6 6.1 |
4.8 3.2 |
..... | 3.18 | 3.18 | 3.96 | 3.43 | ..... | ..... | 2.41 | 3.15 | ..... | 9.5 | 11.0 | 11.0 | ..... | 8.0 | 8.0 | ..... | 6.5 | 16.0 | 1.0 | 1.5 | 1.0 | 4.8 | 6.4 | ..... |
| 8 | 1/4 | 14.6 14.2 |
10.0 8.5 |
7.1 5.6 |
..... | 3.78 | 3.30 | 4.60 | 4.01 | ..... | ..... | 3.02 | 3.68 | ..... | 9.5 | 11.0 | 13.5 | ..... | 8.0 | 8.0 | ..... | 6.5 | 16.0 | 1.0 | 1.5 | 1.0 | 4.8 | 6.4 | ..... |
| 10 | 3/8 | 18.0 17.6 |
13.3 11.8 |
9.9 8.4 |
..... | 4.01 | 3.50 | 5.03 | 4.37 | ..... | ..... | 3.20 | 4.01 | ..... | 9.5 | 13.5 | 15.5 | ..... | 8.0 | 11.0 | ..... | 6.5 | 17.5 | 1.5 | 3.0 | 1.5 | 4.8 | 6.4 | ..... |
| 15 | 1/2 | 22.2 21.8 |
16.6 15.0 |
12.5 11.0 |
7.2 5.6 |
4.67 | 4.09 | 5.97 | 5.18 | 9.35 | 8.18 | 3.73 | 4.78 | 7.47 | 9.5 | 15.5 | 19.0 | 25.5 | 11.0 | 12.5 | 15.5 | 9.5 | 22.5 | 1.5 | 3.0 | 1.5 | 6.4 | 7.9 | 11.2 |
| 20 | 3/4 | 27.6 27.2 |
21.7 20.2 |
16.3 14.8 |
11.8 10.3 |
4.90 | 4.27 | 6.96 | 6.04 | 9.78 | 8.56 | 3.91 | 5.56 | 7.82 | 12.5 | 19.0 | 22.5 | 28.5 | 13.0 | 14.0 | 19.0 | 9.5 | 24.0 | 1.5 | 3.0 | 1.5 | 6.4 | 7.9 | 12.7 |
| 25 | 1 | 34.3 33.9 |
27.4 25.9 |
21.5 19.9 |
16.0 14.4 |
5.69 | 4.89 | 7.92 | 6.93 | 11.38 | 9.96 | 4.55 | 6.35 | 9.09 | 12.5 | 22.5 | 27.0 | 32.0 | 14.0 | 17.5 | 20.5 | 12.5 | 28.5 | 2.0 | 4.0 | 2.0 | 9.6 | 11.2 | 14.7 |
| 32 | 1.1/4 | 43.1 42.7 |
35.8 34.3 |
30.2 28.7 |
23.5 22.0 |
6.07 | 5.28 | 7.92 | 6.93 | 12.14 | 10.96 | 4.85 | 6.35 | 9.70 | 12.5 | 27.0 | 32.0 | 35.0 | 17.5 | 20.5 | 22.5 | 12.5 | 30.0 | 2.0 | 4.0 | 2.0 | 9.6 | 11.2 | 14.2 |
| 40 | 1.1/2 | 49.2 48.8 |
41.6 40.1 |
34.7 33.2 |
28.7 27.2 |
6.35 | 5.54 | 8.92 | 7.80 | 12.70 | 11.12 | 5.08 | 7.14 | 10.15 | 12.5 | 32.0 | 38.0 | 38.0 | 20.5 | 25.5 | 25.5 | 12.5 | 32.0 | 2.0 | 4.0 | 2.0 | 11.2 | 12.7 | 15.7 |
| 50 | 2 | 61.7 61.2 |
53.3 51.7 |
43.6 42.1 |
38.9 37.4 |
6.93 | 6.04 | 10.92 | 9.50 | 13.84 | 12.12 | 5.54 | 8.74 | 11.07 | 16.0 | 38.0 | 41.0 | 54.0 | 25.5 | 28.5 | 28.5 | 19.0 | 41.0 | 2.0 | 4.0 | 2.0 | 12.7 | 15.7 | 19.0 |
| 65 | 2.12 | 74.4 73.9 |
64.2 61.2 |
..... | ..... | 8.76 | 7.67 | ..... | ..... | ..... | ..... | 7.01 | ..... | ..... | 16.0 | 41.0 | ..... | ..... | 28.5 | ..... | ..... | 19.0 | 43.0 | 2.5 | 5.0 | 2.5 | 15.7 | 19.0 | ..... |
| 80 | 3 | 90.3 89.8 |
79.4 76.4 |
..... | ..... | 9.52 | 8.30 | ..... | ..... | ..... | ..... | 7.62 | ..... | ..... | 16.0 | 57.0 | ..... | ..... | 32.0 | ..... | ..... | 19.0 | 44.5 | 2.5 | 5.0 | 2.5 | 19.0 | 22.4 | ..... |
| 100 | 4 | 115.7 115.2 |
103.8 100.7 |
..... | ..... | 10.69 | 9.35 | ..... | ..... | ..... | ..... | 8.56 | ..... | ..... | 19.0 | 66.5 | ..... | ..... | 41.0 | ..... | ..... | 19.0 | 48.0 | 2.5 | 5.0 | 2.5 | 22.4 | 28.4 | ..... |
WHY OUR SOCKET WELD TEE MATTERS
Engineered for Strong, Leak-Proof Socket Weld Connections
Our ASME B16.11 Socket Weld Tee is manufactured from premium forged steel to provide secure 90° branch connections in high-pressure piping systems. The precision-machined socket ends ensure proper pipe alignment, strong welded joints, and long-lasting performance. Designed for demanding industrial applications, it offers excellent pressure resistance, corrosion protection, and dependable service life.
Precision Socket Ends
Accurately machined socket ends provide perfect pipe alignment, secure welding, and leak-proof branch connections.
High-Pressure Performance
Designed to withstand high pressure and temperature conditions while maintaining exceptional strength and structural integrity.
Superior Corrosion Resistance
Manufactured from premium forged materials with a precision finish for excellent resistance to corrosion, oxidation.
Call Us Now
+91 82381 09678
FREQUENTLY ASKED QUESTIONS
Frequently Asked Questions About Our Socket Weld Tee
Find answers to the most common questions about our 3000 LBS. ASME B16.11 Socket Weld Tee, including material quality, pressure rating, standards, applications, and installation.
“Our Socket Weld Tee delivers superior strength, leak-proof connections, and reliable performance for high-pressure piping systems.”
Our Socket Weld Tee is manufactured from premium-quality forged stainless steel, carbon steel, alloy steel, and duplex steel, ensuring exceptional strength, durability, and corrosion resistance.
Our Socket Weld Tee is manufactured in accordance with ASME B16.11 standards and is available in various ASTM material grades to meet industrial requirements.
The Socket Weld Tee is available in 3000 LBS, 6000 LBS, and 9000 LBS pressure ratings for demanding industrial piping applications.
