Dimension Details
| Pcd (mm) | Size Nb | No Of Holes | Thickness (mm) | Od Of Flange (mm) | Diam.meter Of Bolt (mm) | Diam.meter Of Bore (mm) |
|---|---|---|---|---|---|---|
| 60.3 | 15NB | 4 | 11.1 | 88.9 | 12.7 | 22.40 |
| 69.9 | 20NB | 4 | 12.7 | 98.4 | 12.7 | 27.70 |
| 79.4 | 25NB | 4 | 14.3 | 108.0 | 12.7 | 34.50 |
| 88.9 | 32NB | 4 | 15.9 | 117.5 | 12.7 | 43.20 |
| 98.4 | 40NB | 4 | 17.5 | 127.0 | 12.7 | 49.50 |
| 120.7 | 50NB | 4 | 19.1 | 152.4 | 15.9 | 62 |
| 139.7 | 65NB | 4 | 22.2 | 177.8 | 15.9 | 74.70 |
| 152.4 | 80NB | 4 | 23.8 | 190.5 | 15.9 | 90.70 |
| 190.5 | 100NB | 8 | 23.8 | 228.6 | 15.9 | 116.10 |
| 215.9 | 125NB | 8 | 23.8 | 254.0 | 19.1 | 143.80 |
| 241.3 | 150NB | 8 | 25.4 | 279.4 | 19.1 | 170.70 |
| 298.5 | 200NB | 8 | 28.6 | 342.9 | 19.1 | 221.50 |
| 362.0 | 250NB | 12 | 30.2 | 406.4 | 22.2 | 276.40 |
| 431.8 | 300NB | 12 | 31.8 | 482.6 | 22.2 | 327.20 |
| 476.3 | 350NB | 12 | 34.9 | 533.4 | 25.4 | 349.20 |
| 539.8 | 400NB | 16 | 36.5 | 596.9 | 25.4 | 410.50 |
| 577.9 | 450NB | 16 | 39.7 | 635.0 | 28.6 | 461.80 |
| 635.0 | 500NB | 20 | 42.9 | 698.5 | 28.6 | 513.10 |
All Dimensions in MM
Technical Dimensions
| B | D | C | G | J | A | E | F | A | E | F | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Nominal Pipe Size |
Socket Bore dia. B (Note [1]) |
Bore Diameter of Fittings, D [Note (1)] |
Socket Wall Thickness, C | Body Wall | Min Depth of Socket |
Center to Bottom of Socket, A | Laying Lengths |
Tolerances ± | End Wall Thickness Kmin |
||||||||||||||||||||
| Class Designation | Class Designation | Class Designation | 90 deg Elbows, Tees and Crosses |
45 deg Elbows | Class Designation | ||||||||||||||||||||||||
| 3000 | 6000 | 9000 | 3000 | 6000 | 9000 | 3000 | 6000 | 9000 | Class Designation | Coupl- ings, E |
Half Coupl- ings, F |
A | E | F | 3000 | 6000 | 9000 | ||||||||||||
| (mm) | (Inch) | 3000 | 6000 | 9000 | Agv. | Min. | Agv. | Min. | Agv. | Min. | Min. | Min. | Min. | J | 3000 | 6000 | 9000 | 3000 | 6000 | 9000 | |||||||||
| 6 | 1/8 | 11.2 10.8 |
7.6 6.1 |
4.8 3.2 |
..... | 3.18 | 3.18 | 3.96 | 3.43 | ..... | ..... | 2.41 | 3.15 | ..... | 9.5 | 11.0 | 11.0 | ..... | 8.0 | 8.0 | ..... | 6.5 | 16.0 | 1.0 | 1.5 | 1.0 | 4.8 | 6.4 | ..... |
| 8 | 1/4 | 14.6 14.2 |
10.0 8.5 |
7.1 5.6 |
..... | 3.78 | 3.30 | 4.60 | 4.01 | ..... | ..... | 3.02 | 3.68 | ..... | 9.5 | 11.0 | 13.5 | ..... | 8.0 | 8.0 | ..... | 6.5 | 16.0 | 1.0 | 1.5 | 1.0 | 4.8 | 6.4 | ..... |
| 10 | 3/8 | 18.0 17.6 |
13.3 11.8 |
9.9 8.4 |
..... | 4.01 | 3.50 | 5.03 | 4.37 | ..... | ..... | 3.20 | 4.01 | ..... | 9.5 | 13.5 | 15.5 | ..... | 8.0 | 11.0 | ..... | 6.5 | 17.5 | 1.5 | 3.0 | 1.5 | 4.8 | 6.4 | ..... |
| 15 | 1/2 | 22.2 21.8 |
16.6 15.0 |
12.5 11.0 |
7.2 5.6 |
4.67 | 4.09 | 5.97 | 5.18 | 9.35 | 8.18 | 3.73 | 4.78 | 7.47 | 9.5 | 15.5 | 19.0 | 25.5 | 11.0 | 12.5 | 15.5 | 9.5 | 22.5 | 1.5 | 3.0 | 1.5 | 6.4 | 7.9 | 11.2 |
| 20 | 3/4 | 27.6 27.2 |
21.7 20.2 |
16.3 14.8 |
11.8 10.3 |
4.90 | 4.27 | 6.96 | 6.04 | 9.78 | 8.56 | 3.91 | 5.56 | 7.82 | 12.5 | 19.0 | 22.5 | 28.5 | 13.0 | 14.0 | 19.0 | 9.5 | 24.0 | 1.5 | 3.0 | 1.5 | 6.4 | 7.9 | 12.7 |
| 25 | 1 | 34.3 33.9 |
27.4 25.9 |
21.5 19.9 |
16.0 14.4 |
5.69 | 4.89 | 7.92 | 6.93 | 11.38 | 9.96 | 4.55 | 6.35 | 9.09 | 12.5 | 22.5 | 27.0 | 32.0 | 14.0 | 17.5 | 20.5 | 12.5 | 28.5 | 2.0 | 4.0 | 2.0 | 9.6 | 11.2 | 14.7 |
| 32 | 1.1/4 | 43.1 42.7 |
35.8 34.3 |
30.2 28.7 |
23.5 22.0 |
6.07 | 5.28 | 7.92 | 6.93 | 12.14 | 10.96 | 4.85 | 6.35 | 9.70 | 12.5 | 27.0 | 32.0 | 35.0 | 17.5 | 20.5 | 22.5 | 12.5 | 30.0 | 2.0 | 4.0 | 2.0 | 9.6 | 11.2 | 14.2 |
| 40 | 1.1/2 | 49.2 48.8 |
41.6 40.1 |
34.7 33.2 |
28.7 27.2 |
6.35 | 5.54 | 8.92 | 7.80 | 12.70 | 11.12 | 5.08 | 7.14 | 10.15 | 12.5 | 32.0 | 38.0 | 38.0 | 20.5 | 25.5 | 25.5 | 12.5 | 32.0 | 2.0 | 4.0 | 2.0 | 11.2 | 12.7 | 15.7 |
| 50 | 2 | 61.7 61.2 |
53.3 51.7 |
43.6 42.1 |
38.9 37.4 |
6.93 | 6.04 | 10.92 | 9.50 | 13.84 | 12.12 | 5.54 | 8.74 | 11.07 | 16.0 | 38.0 | 41.0 | 54.0 | 25.5 | 28.5 | 28.5 | 19.0 | 41.0 | 2.0 | 4.0 | 2.0 | 12.7 | 15.7 | 19.0 |
| 65 | 2.12 | 74.4 73.9 |
64.2 61.2 |
..... | ..... | 8.76 | 7.67 | ..... | ..... | ..... | ..... | 7.01 | ..... | ..... | 16.0 | 41.0 | ..... | ..... | 28.5 | ..... | ..... | 19.0 | 43.0 | 2.5 | 5.0 | 2.5 | 15.7 | 19.0 | ..... |
| 80 | 3 | 90.3 89.8 |
79.4 76.4 |
..... | ..... | 9.52 | 8.30 | ..... | ..... | ..... | ..... | 7.62 | ..... | ..... | 16.0 | 57.0 | ..... | ..... | 32.0 | ..... | ..... | 19.0 | 44.5 | 2.5 | 5.0 | 2.5 | 19.0 | 22.4 | ..... |
| 100 | 4 | 115.7 115.2 |
103.8 100.7 |
..... | ..... | 10.69 | 9.35 | ..... | ..... | ..... | ..... | 8.56 | ..... | ..... | 19.0 | 66.5 | ..... | ..... | 41.0 | ..... | ..... | 19.0 | 48.0 | 2.5 | 5.0 | 2.5 | 22.4 | 28.4 | ..... |
